John Deere 744J and 824J Loader Repair Technical Manual (TM2084)
John Deere 744j Specs
TM2084 - 744J and 824J Loader Repair Manual.pdf
705 pages, bookmarked, Searchable, Printable, high quality PDF
Complete Repair Technical Manual for John Deere 744J and 824J Loader. It's the same service manual used by dealers that guaranteed to be fully functional and intact without any missing page.
Ag, Turf, & Engine Operator Manuals & Publications. Discover how to find, view, and purchase technical and service manuals and parts catalogs for your John Deere equipment. Purchase Manuals and Publications Online; Find a Parts Catalog; View Operator Manual Engine Maintenance Information. John Deere can equip your 724J,744J, or 824J with exactly what you needto be productive in your kind of work. Vertis QCA DKAJPLDR P 1300 19th Street, Suite 200 East Moline, IL61244 Cyan Magenta Yellow Black DKAJPLDR Page 10 DKAJPLDRADV 2/25/05 2:37 PM Page 10.
John Deere 744J and 824J Loader Repair Technical Manual (including maintenance, overhaul, disassembling & assembling, adjustment, tune-up, operation, inspecting, diagnostic & troubleshooting…) is divided into different sections. Each section covers a specific component or system with detailed illustrations. A table of contents is placed at the beginning of each section. Pages are easily found by category, and each page is expandable for great detail. The printer-ready PDF documents work like a charm on all kinds of devices.
John Deere 744k Operators Manual
EXCERPT:
TM2084 - 744J and 824J Loader Repair
Pilot Controller Disassemble and Assemble—Single Lever Controller (S.N. —590067)
Before Pilot Control Valve is disassembled the following checks should be done first to help isolate confirm the problem is in the pilot controller. Perform Pilot Control Valve Pressure Test . (Group 9025-25.) Perform Pressure Reducing Valve Pressure Test. (Group 9025-25.)
TP55415-UN: Single Lever (Joystick) Assembly
LEGEND:
1 - Grip
2 - Sleeve
3 - Nut
4 - Retainer
5 - Boot
6 - Nut (4 used)
7 - Lever
8 - Set Screw
9 - Washer
10 - Washer
11 - Plug
12 - Plate
13 - Washer
14 - Nut
15 - U-Join (center post)
16 - Ball joint socket (3 used)
17 - Cap Screw (4 used)
18 - Housing (top)
19 - Push Bar
20 - Grommet (4 used)
21 - Strap (4 used)
22 - Terminal Nipple (8 used)
23 - Washer
24 - Pin contact (8 used)
25 - Nut
26 - connector
27 - O-Ring
28 - Electrical Coil (3 used)
29 - Retainer (3 used)
30 - Tube
31 - Back Up Ring
32 - Seal
33 - Ring (2 used)
34 - Retainer (2 used) (Tool Carrier 1 used)
35 - Retainer (2 used) (Tool Carrier 3 used)
36 - Plunger (2 used) (Tool Carrier 1 used)
37 - Plunger (2 used) (Tool Carrier 3 used)
38 - Shim (as required) (0.1 mm / .004 in)
...
